Description
◆ Extends USB 3.0 super speed devices up to 50 m;
◆ Supports all USB 3.0 device types: control, interrupt, bulk and isochronous at up to 5 Gbps;
◆ Operates with USB 3.0 super speed host controllers;
◆ Supports all major operating systems including Windows, Mac OS, and Linux;
◆ Number of devices can be increased using additional hubs;
◆ Host and Remote devices need to be self-powered.
notes：Support USB1.1 Keyboard/Mouse within 15m ; Longer than 15m Support USB2.0 only, without USB1.1
Fully compliant with the USB 3.0 standard protocol, supporting 5Gbps transmission bandwidth.
- Utilizes imported II-VI (USA) laser + Silicon Line (Germany) driver chip.
- Uses OM3 10G-grade pure fiber optic cable + copper core wire as the transmission medium, featuring a built-in photoelectric conversion engine.
- Reinforced with Kevlar fiber (bullet-proof material) for enhanced cable durability, strength, and resistance to pulling.
- Supports transmission distances up to 60 meters (longer custom lengths available subject to specific device compatibility).
- Supports plug-and-play functionality; no external power supply required.
- Offers two options: backward compatible with lower versions or non-backward compatible.
- Features specialized fiber optic cable with a diameter of only 4.8mm, making installation and routing easier.
- Provides excellent anti-radiation and interference resistance, perfectly solving EMI/RFI (Electromagnetic Interference/Radio Frequency Interference) problems for lossless signal transmission.
- Compatible with all mainstream operating systems, including Windows, macOS, and Linux.
- Rigorously tested in laboratories and across numerous brands and models of equipment, ensuring full compatibility with USB standard devices.
- Widely applicable in industrial cameras, medical equipment systems, security surveillance, conference engineering, broadcast systems, marine vessels, printers, scanners, hard disk drives, audio equipment, touch screens, webcams, and game controllers.
-
PRODUCT INTRODUCTION
Product Name: HybridOptical Series Fiber Optic USB 3.0 Type A to Micro B Cable
Core Features: Data Transmission, Charging Function
Length: 0-60m (Custom lengths available; available in backward compatible and non-backward compatible versions)
Applications:- Printers, scanners, hard disk drives, audio equipment
- Touchscreens, webcams, game controllers
- Computers, graphics cards, monitors, projectors, VR devices, cameras, etc.
CONNECTOR
Interface Type: USB Type A Male to Micro B Male
Interface Version: USB 3.0
Terminal Material: Copper Shell
CHIP
Photoelectric Conversion Engine: 4-channel 850 nm VCSEL array + 4-channel GaAs PD array
Core Components: Laser + VCSEL driver chip + PD receiver amplifier chip + Lens + Jumper
Laser/Driver: II-VI (USA) + Silicon Line (Germany)
Lifespan: >60,000 hours (lab-accelerated aging test)CABLE
Filling: Kevlar fiber (aramid)
Core Structure: OM3 10Gbps fiber optic + copper coreJacket: Eco-friendly PVC
Cable Diameter: φ4.8mm
HOUSING
Material: Zinc alloy
Dimensions: 39 * 19 * 9mm (Type A) / 46 * 23 * 9mm (Micro B)
Process: Electroplating
Color: Classic Gray
FUNCTIONS
Bandwidth: 5GbpsCharging: 5V 900mA (MAX)
Compatible OS: Windows, macOS, Linux
CHARACTERISTICS
Min. Bend Radius (Dynamic/Static): 20mm
Bit Error Rate: ≤0.0035dB/m
Operating Temperature: -20℃ ~ +70℃
Storage Temperature: -20℃ ~ +60℃
Operating Humidity: <90% (non-condensing)
Power Supply: TX: 0.5W, RX: 0.5W, 5VDC
Power Consumption: 250mW
External Power: Not required
Tensile Force (Long-term/Short-term): 100N/200N
Crush Resistance (Long-term/Short-term): 200N/400N
Flame Rating: CL3
Indicator Light: None
CERTIFICATIONS
Standards: CE, FCC, UL, RoHS, RE
